MAL212546822E3
Vishay BC Components/Beyshlag/Draloric
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 8200UF 25V 10000H
- CategoryAluminum Electrolytic Capacitors
-
ECAD Model
- Share
In Stock: 143
Can ship immediately
Pricing:
- 1$4.928
Quote It
Technical Details
- Series:125 ALS
- Package:Box
- Part Status:Active
- Capacitance:8200 µF
- Tolerance:±20%
- Voltage - Rated:25 V
- ESR (Equivalent Series Resistance):46mOhm @ 100Hz
- Lifetime @ Temp.:10000 Hrs @ 105°C
- Operating Temperature:-40°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:1.75 A @ 100 Hz
- Ripple Current @ High Frequency:2.275 A @ 10 kHz
- Impedance:58 mOhms
- Lead Spacing:-
- Size / Dimension:0.827" Dia x 1.496" L (21.00mm x 38.00mm)
- Height - Seated (Max):-
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Axial, Can
