LKS1E273MESB

Technical Details

• Series:LKS
• Package:Bulk
• Part Status:Active
• Capacitance:27000 µF
• Tolerance:±20%
• Voltage - Rated:25 V
• ESR (Equivalent Series Resistance):-
• Lifetime @ Temp.:1000 Hrs @ 85°C
• Operating Temperature:-40°C ~ 85°C
• Polarization:Polar
• Ratings:-

• Applications:Audio
• Ripple Current @ Low Frequency:4.2 A @ 120 Hz
• Ripple Current @ High Frequency:-
• Impedance:-
• Lead Spacing:0.394" (10.00mm)
• Size / Dimension:1.181" Dia (30.00mm)
• Height - Seated (Max):2.047" (52.00mm)
• Surface Mount Land Size:-
• Mounting Type:Through Hole
• Package / Case:Radial, Can - Snap-In
