E92F3J1VSN471MA40U
United Chemi-Con
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 470UF 20% 385V SNAP
- CategoryAluminum Electrolytic Capacitors
-
ECAD Model
- Share
In Stock: 103
Can ship immediately
Pricing:
- 1$5.46
Quote It
Technical Details
- Series:U92F
- Package:Bulk
- Part Status:Active
- Capacitance:470 µF
- Tolerance:±20%
- Voltage - Rated:385 V
- ESR (Equivalent Series Resistance):195mOhm @ 120Hz
- Lifetime @ Temp.:5000 Hrs @ 85°C
- Operating Temperature:-25°C ~ 85°C
- Polarization:Polar
- Ratings:-
- Applications:-
- Ripple Current @ Low Frequency:3.1 A @ 120 Hz
- Ripple Current @ High Frequency:4.433 A @ 100 kHz
- Impedance:-
- Lead Spacing:0.394" (10.00mm)
- Size / Dimension:1.378" Dia (35.00mm)
- Height - Seated (Max):1.673" (42.50mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can - Snap-In
