B43644A2228M060
TDK EPCOS
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionALUM ELECT 200V 2200UF SNAP-IN
- CategoryAluminum Electrolytic Capacitors
-
ECAD Model
- Share
In Stock: 192
Can ship immediately
Pricing:
- 1$6.08
Quote It
Technical Details
- Series:B43644
- Package:Bulk
- Part Status:Active
- Capacitance:2200 µF
- Tolerance:±20%
- Voltage - Rated:200 V
- ESR (Equivalent Series Resistance):55mOhm @ 100Hz
- Lifetime @ Temp.:5000 Hrs @ 105°C
- Operating Temperature:-40°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:3.94 A @ 100 Hz
- Ripple Current @ High Frequency:-
- Impedance:85 mOhms
- Lead Spacing:0.394" (10.00mm)
- Size / Dimension:1.181" Dia (30.00mm)
- Height - Seated (Max):2.244" (57.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can - Snap-In
