THA331M150AA0C

Technical Details

• Series:THA
• Package:Bulk
• Part Status:Active
• Capacitance:330 µF
• Tolerance:±20%
• Voltage - Rated:150 V
• ESR (Equivalent Series Resistance):800mOhm @ 120Hz
• Lifetime @ Temp.:5000 Hrs @ 85°C
• Operating Temperature:-55°C ~ 85°C
• Polarization:Polar
• Ratings:-

• Applications:General Purpose
• Ripple Current @ Low Frequency:600 mA @ 120 Hz
• Ripple Current @ High Frequency:1.02 A @ 20 kHz
• Impedance:-
• Lead Spacing:0.394" (10.00mm)
• Size / Dimension:1.433" L x 0.953" W (36.40mm x 24.20mm)
• Height - Seated (Max):0.335" (8.50mm)
• Surface Mount Land Size:-
• Mounting Type:Through Hole
• Package / Case:FlatPack
