E36D630HLS333MAE3U
United Chemi-Con
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 33000UF 20% 63V SCREW
- CategoryAluminum Electrolytic Capacitors
-
ECAD Model
- Share
In Stock: 116
Can ship immediately
Pricing:
- 1$17.8939
Quote It
Technical Details
- Series:U36D
- Package:Bulk
- Part Status:Active
- Capacitance:33000 µF
- Tolerance:±20%
- Voltage - Rated:63 V
- ESR (Equivalent Series Resistance):9.7mOhm @ 120Hz
- Lifetime @ Temp.:2000 Hrs @ 85°C
- Operating Temperature:-40°C ~ 85°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:10.75 A @ 120 Hz
- Ripple Current @ High Frequency:15.05 A @ 3 kHz
- Impedance:-
- Lead Spacing:0.500" (12.70mm)
- Size / Dimension:1.375" Dia (34.93mm)
- Height - Seated (Max):5.625" (142.88mm)
- Surface Mount Land Size:-
- Mounting Type:Chassis Mount
- Package / Case:Radial, Can - Screw Terminals
