CGS333U010R3C
Cornell Dubilier Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 33000UF 10V SCREW
- CategoryAluminum Electrolytic Capacitors
- Datasheet CGS333U010R3C Datasheet
-
ECAD Model
- Share
In Stock: 188
Can ship immediately
Pricing:
- 1$18.0112
- 100$17.5697
Quote It
Technical Details
- Series:CGS
- Package:Bulk
- Part Status:Active
- Capacitance:33000 µF
- Tolerance:-10%, +75%
- Voltage - Rated:10 V
- ESR (Equivalent Series Resistance):18mOhm @ 120Hz
- Lifetime @ Temp.:2000 Hrs @ 85°C
- Operating Temperature:-40°C ~ 85°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:7.4 A @ 120 Hz
- Ripple Current @ High Frequency:9.62 A @ 10 kHz
- Impedance:-
- Lead Spacing:-
- Size / Dimension:1.375" Dia (34.93mm)
- Height - Seated (Max):3.125" (79.38mm)
- Surface Mount Land Size:-
- Mounting Type:Chassis Mount
- Package / Case:Radial, Can - Screw Terminals
