MAL210157153E3
Vishay BC Components/Beyshlag/Draloric- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 15000UF 20% 40V SCREW
- CategoryAluminum Electrolytic Capacitors
- Datasheet MAL210157153E3 Datasheet
-
ECAD Model
- Share
In Stock: 121
Can ship immediately
Pricing:
- 1$18.9945
- 300$18.224
Quote It
Technical Details
- Series:101 PHR-ST
- Package:Bulk
- Part Status:Active
- Capacitance:15000 µF
- Tolerance:±20%
- Voltage - Rated:40 V
- ESR (Equivalent Series Resistance):28mOhm @ 100Hz
- Lifetime @ Temp.:10000 Hrs @ 85°C
- Operating Temperature:-40°C ~ 85°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:7.8 A @ 100 Hz
- Ripple Current @ High Frequency:-
- Impedance:22 mOhms
- Lead Spacing:0.504" (12.80mm)
- Size / Dimension:1.378" Dia (35.00mm)
- Height - Seated (Max):2.744" (69.70mm)
- Surface Mount Land Size:-
- Mounting Type:Chassis Mount
- Package / Case:Radial, Can - Screw Terminals
