ERWE401LGB821MAA0U
United Chemi-Con- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 820UF 20% 400V SCREW
- CategoryAluminum Electrolytic Capacitors
-
ECAD Model
- Share
In Stock: 108
Can ship immediately
Pricing:
- 1$19.85633
Quote It
Technical Details
- Series:RWE
- Package:Bulk
- Part Status:Active
- Capacitance:820 µF
- Tolerance:±20%
- Voltage - Rated:400 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:2000 Hrs @ 85°C
- Operating Temperature:-25°C ~ 85°C
- Polarization:Polar
- Ratings:-
- Applications:-
- Ripple Current @ Low Frequency:3.4 A @ 120 Hz
- Ripple Current @ High Frequency:4.76 A @ 3 kHz
- Impedance:-
- Lead Spacing:0.500" (12.70mm)
- Size / Dimension:1.378" Dia (35.00mm)
- Height - Seated (Max):4.094" (104.00mm)
- Surface Mount Land Size:-
- Mounting Type:Chassis Mount
- Package / Case:Radial, Can - Screw Terminals
