E91F501VND561MAA0U
United Chemi-Con
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 560UF 20% 500V SNAP
- CategoryAluminum Electrolytic Capacitors
-
ECAD Model
- Share
In Stock: 180
Can ship immediately
Pricing:
- 1$20.2645
Quote It
Technical Details
- Series:U91F
- Package:Bulk
- Part Status:Active
- Capacitance:560 µF
- Tolerance:±20%
- Voltage - Rated:500 V
- ESR (Equivalent Series Resistance):142mOhm @ 120Hz
- Lifetime @ Temp.:5000 Hrs @ 105°C
- Operating Temperature:-25°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:-
- Ripple Current @ Low Frequency:3.7 A @ 120 Hz
- Ripple Current @ High Frequency:5.291 A @ 100 kHz
- Impedance:-
- Lead Spacing:0.886" (22.50mm)
- Size / Dimension:1.378" Dia (35.00mm)
- Height - Seated (Max):4.035" (102.50mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can - Snap-In - 4 Lead
