E32D160HPN184MC92U
United Chemi-Con- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 180000UF 20% 16V SCREW
- CategoryAluminum Electrolytic Capacitors
-
ECAD Model
- Share
In Stock: 150
Can ship immediately
Pricing:
- 1$22.8802
Quote It
Technical Details
- Series:U32D
- Package:Bulk
- Part Status:Active
- Capacitance:180000 µF
- Tolerance:±20%
- Voltage - Rated:16 V
- ESR (Equivalent Series Resistance):7.5mOhm @ 120Hz
- Lifetime @ Temp.:2000 Hrs @ 105°C
- Operating Temperature:-40°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:22.89 A @ 120 Hz
- Ripple Current @ High Frequency:25.6368 A @ 50 kHz
- Impedance:-
- Lead Spacing:0.875" (22.22mm)
- Size / Dimension:2.000" Dia (50.80mm)
- Height - Seated (Max):3.661" (93.00mm)
- Surface Mount Land Size:-
- Mounting Type:Chassis Mount
- Package / Case:Radial, Can - Screw Terminals
