UHC1E100MDD

Technical Details

• Series:UHC
• Package:Bulk
• Part Status:Obsolete
• Capacitance:10 µF
• Tolerance:±20%
• Voltage - Rated:25 V
• ESR (Equivalent Series Resistance):-
• Lifetime @ Temp.:1000 Hrs @ 105°C
• Operating Temperature:-40°C ~ 105°C
• Polarization:Polar
• Ratings:-

• Applications:High Temperature Reflow
• Ripple Current @ Low Frequency:92 mA @ 120 Hz
• Ripple Current @ High Frequency:230 mA @ 100 kHz
• Impedance:520 mOhms
• Lead Spacing:0.059" (1.50mm)
• Size / Dimension:0.157" Dia (4.00mm)
• Height - Seated (Max):0.276" (7.00mm)
• Surface Mount Land Size:-
• Mounting Type:Through Hole
• Package / Case:Radial, Can
