5-146465-5
TE Connectivity AMP Connectors
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN HDR 5POS 0.1 STACK T/H TIN
- CategoryRectangular Connectors - Board Spacers, Stackers (Board to Board)
- Datasheet 5-146465-5 Datasheet
-
ECAD Model
- Share
In Stock: 448
Can ship immediately
Pricing:
- 1$2.06
- 10$1.8678
- 100$1.60064
- 500$1.33388
- 1,000$1.14333
- 5,000$1.01375
- 10,000$0.99089
Quote It
Technical Details
- Series:AMPMODU Mod II
- Package:Bulk
- Part Status:Active
- Number of Positions:5
- Pitch:0.100" (2.54mm)
- Number of Rows:1
- Row Spacing:-
- Length - Overall Pin:0.930" (23.622mm)
- Length - Post (Mating):0.120" (3.050mm)
- Length - Stack Height:0.700" (17.780mm)
- Length - Tail:0.110" (2.800mm)
- Mounting Type:Through Hole
- Termination:Solder
- Contact Finish - Post (Mating):Tin
- Contact Finish Thickness - Post (Mating):100.0µin (2.54µm)
- Color:Black
