75970-394-02LF
Storage & Server IO (Amphenol ICC)- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN HDR 2POS 0.1 STACK T/H TIN
- CategoryRectangular Connectors - Board Spacers, Stackers (Board to Board)
- Datasheet 75970-394-02LF Datasheet
-
ECAD Model
- Share
In Stock: 177
Can ship immediately
Pricing:
- 1$0.10746
- 1,000$0.09936
Quote It
Technical Details
- Series:BERGSTIK®, MezzSelect™, Basics+
- Package:Bag
- Part Status:Active
- Number of Positions:2
- Pitch:0.100" (2.54mm)
- Number of Rows:1
- Row Spacing:-
- Length - Overall Pin:0.564" (14.326mm)
- Length - Post (Mating):0.130" (3.300mm)
- Length - Stack Height:0.304" (7.722mm)
- Length - Tail:0.130" (3.300mm)
- Mounting Type:Through Hole
- Termination:Solder
- Contact Finish - Post (Mating):Tin
- Contact Finish Thickness - Post (Mating):78.7µin (2.00µm)
- Color:Black
