M22-2681046
Harwin
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN HDR 20POS 0.079 STACK T/H
- CategoryRectangular Connectors - Board Spacers, Stackers (Board to Board)
- Datasheet M22-2681046 Datasheet
-
ECAD Model
- Share
In Stock: 194
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:M22
- Package:Bulk
- Part Status:Obsolete
- Number of Positions:20
- Pitch:0.079" (2.00mm)
- Number of Rows:2
- Row Spacing:0.079" (2.00mm)
- Length - Overall Pin:0.705" (17.900mm)
- Length - Post (Mating):0.138" (3.500mm)
- Length - Stack Height:0.472" (12.000mm)
- Length - Tail:0.094" (2.400mm)
- Mounting Type:Through Hole
- Termination:Solder
- Contact Finish - Post (Mating):Tin
- Contact Finish Thickness - Post (Mating):-
- Color:Black
