VSBU-120-T125B
CUI Inc.
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionAC/DC CONVERTER 5V 12V 5V 120W
- CategoryAC DC Converters
- Datasheet VSBU-120-T125B Datasheet
-
ECAD Model
- Share
In Stock: 110
Can ship immediately
Pricing:
- 1$86.82525
- 50$86.8252
Quote It
Technical Details
- Series:VSBU-120-T (120W)
- Package:Box
- Part Status:Not For New Designs
- Type:Open Frame
- Number of Outputs:3
- Voltage - Input:90 ~ 260 VAC
- Voltage - Output 1:5V
- Voltage - Output 2:12V
- Voltage - Output 3:5V
- Voltage - Output 4:-
- Current - Output (Max):15A, 6A, 800mA
- Power (Watts):120W
- Applications:ITE (Commercial)
- Voltage - Isolation:4.242 kV
- Efficiency:80%
- Operating Temperature:0°C ~ 70°C
- Features:PFC, Universal Input
- Mounting Type:Chassis Mount
- Size / Dimension:5.00" L x 3.00" W x 1.28" H (127.0mm x 76.2mm x 32.5mm)
- Approval Agency:CB Scheme, EN, IEC, SIQ, TUV, UL
- Standard Number:55024; 55032 Class B; 60950-1; 61000-3-2; 61000-3-3
