VF-D320-D512A
CUI Inc.
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionAC/DC CONVERTER 5V 12V 320W
- CategoryAC DC Converters
- Datasheet VF-D320-D512A Datasheet
-
ECAD Model
- Share
In Stock: 138
Can ship immediately
Pricing:
- 1$130.54
- 250$115.56
Quote It
Technical Details
- Series:VF-D320-D (300W)
- Package:Box
- Part Status:Active
- Type:Open Frame
- Number of Outputs:2
- Voltage - Input:90 ~ 132 VAC, 180 ~ 264 VAC
- Voltage - Output 1:5V
- Voltage - Output 2:12V
- Voltage - Output 3:-
- Voltage - Output 4:-
- Current - Output (Max):30A, 16.67A
- Power (Watts):320W
- Applications:ITE (Commercial)
- Voltage - Isolation:3 kV
- Efficiency:75%
- Operating Temperature:0°C ~ 70°C (With Derating)
- Features:Adjustable Output, PFC, Universal Input
- Mounting Type:Chassis Mount
- Size / Dimension:6.00" L x 4.00" W x 1.50" H (152.4mm x 101.6mm x 38.1mm)
- Approval Agency:CB Scheme, EN, IEC, SIQ, TUV, UL
- Standard Number:55024; 55032 Class B; 61000-3-2; 61000-3-3; 62368-1
