SCT45

Technical Details

• Series:SC40 (40W)
• Package:Bulk
• Part Status:Obsolete
• Type:Open Frame
• Number of Outputs:3
• Voltage - Input:85 ~ 265 VAC
• Voltage - Output 1:5V
• Voltage - Output 2:15V
• Voltage - Output 3:-15V
• Voltage - Output 4:-
• Current - Output (Max):4A, 2A, 500mA

• Power (Watts):40W (55W Forced Air)
• Applications:ITE (Commercial)
• Voltage - Isolation:4.3 kV
• Efficiency:70%
• Operating Temperature:0°C ~ 70°C (With Derating)
• Features:Adjustable Output, Universal Input
• Mounting Type:Chassis Mount
• Size / Dimension:5.00" L x 3.00" W x 1.00" H (127.0mm x 76.2mm x 25.4mm)
• Approval Agency:CE
• Standard Number:-
