EEC05DRYH-S13
Sullins Connector Solutions
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN EDGE DUAL FMALE 10POS 0.100
- CategoryCard Edge Connectors - Edgeboard Connectors
- Datasheet EEC05DRYH-S13 Datasheet
-
ECAD Model
- Share
In Stock: 191
Can ship immediately
Pricing:
- 1$3.408
- 10$3.408
Quote It
Technical Details
- Series:-
- Package:Tube
- Part Status:Active
- Card Type:Non Specified - Dual Edge
- Gender:Female
- Number of Positions/Bay/Row:5
- Number of Positions:10
- Card Thickness:0.062" (1.57mm)
- Number of Rows:2
- Pitch:0.100" (2.54mm)
- Read Out:Dual
- Features:Card Extender
- Mounting Type:Board Edge, Straddle Mount
- Termination:Solder
- Contact Material:Phosphor Bronze
- Contact Finish:Tin
- Contact Finish Thickness:100.0µin (2.54µm)
- Contact Type:Full Bellows
- Color:Blue
- Flange Feature:Top Mount Opening, Unthreaded, 0.125" (3.18mm) Dia
- Operating Temperature:-65°C ~ 125°C
