GBC20DREF
Sullins Connector Solutions
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN EDGE DUAL FMALE 40POS 0.100
- CategoryCard Edge Connectors - Edgeboard Connectors
- Datasheet GBC20DREF Datasheet
-
ECAD Model
- Share
In Stock: 158
Can ship immediately
Pricing:
- 1$6.127
- 10$6.127
Quote It
Technical Details
- Series:-
- Package:Tube
- Part Status:Active
- Card Type:Non Specified - Dual Edge
- Gender:Female
- Number of Positions/Bay/Row:20
- Number of Positions:40
- Card Thickness:0.062" (1.57mm)
- Number of Rows:2
- Pitch:0.100" (2.54mm)
- Read Out:Dual
- Features:-
- Mounting Type:Panel Mount
- Termination:Solder Eyelet(s)
- Contact Material:Phosphor Bronze
- Contact Finish:Gold
- Contact Finish Thickness:10.0µin (0.25µm)
- Contact Type:Full Bellows
- Color:Black
- Flange Feature:Top Mount Opening, Floating Bobbin, 0.116" (2.95mm) Dia
- Operating Temperature:-65°C ~ 125°C
