GEM12DRMT-S288
Sullins Connector Solutions
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN EDGE DUAL FMALE 24POS 0.156
- CategoryCard Edge Connectors - Edgeboard Connectors
- Datasheet GEM12DRMT-S288 Datasheet
-
ECAD Model
- Share
In Stock: 150
Can ship immediately
Pricing:
- 1$6.555
- 10$6.555
Quote It
Technical Details
- Series:-
- Package:Tray
- Part Status:Active
- Card Type:Non Specified - Dual Edge
- Gender:Female
- Number of Positions/Bay/Row:12
- Number of Positions:24
- Card Thickness:0.062" (1.57mm)
- Number of Rows:2
- Pitch:0.156" (3.96mm)
- Read Out:Dual
- Features:Card Extender
- Mounting Type:Board Edge, Straddle Mount
- Termination:Wire Wrap
- Contact Material:Phosphor Bronze
- Contact Finish:Tin
- Contact Finish Thickness:100.0µin (2.54µm)
- Contact Type:Loop Bellows
- Color:Black
- Flange Feature:Flush Mount, Top Opening, Threaded Insert, 4-40
- Operating Temperature:-65°C ~ 125°C
