ASM06DSEP-S243
Sullins Connector Solutions
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN EDGE DUAL FMALE 12POS 0.156
- CategoryCard Edge Connectors - Edgeboard Connectors
- Datasheet ASM06DSEP-S243 Datasheet
-
ECAD Model
- Share
In Stock: 110
Can ship immediately
Pricing:
- 1$6.864
- 10$6.864
Quote It
Technical Details
- Series:-
- Package:Tray
- Part Status:Active
- Card Type:Non Specified - Dual Edge
- Gender:Female
- Number of Positions/Bay/Row:6
- Number of Positions:12
- Card Thickness:0.062" (1.57mm)
- Number of Rows:2
- Pitch:0.156" (3.96mm)
- Read Out:Single
- Features:-
- Mounting Type:Panel Mount
- Termination:Solder Eyelet(s)
- Contact Material:Beryllium Copper
- Contact Finish:Gold
- Contact Finish Thickness:10.0µin (0.25µm)
- Contact Type:Full Bellows
- Color:Green
- Flange Feature:Top Mount Opening, Unthreaded, 0.142" (3.61mm) Dia
- Operating Temperature:-65°C ~ 150°C
