EMC06DRES-S13
Sullins Connector Solutions
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN EDGE DUAL FMALE 12POS 0.100
- CategoryCard Edge Connectors - Edgeboard Connectors
- Datasheet EMC06DRES-S13 Datasheet
-
ECAD Model
- Share
In Stock: 115
Can ship immediately
Pricing:
- 1$7.385
- 10$7.385
Quote It
Technical Details
- Series:-
- Package:Tube
- Part Status:Active
- Card Type:Non Specified - Dual Edge
- Gender:Female
- Number of Positions/Bay/Row:6
- Number of Positions:12
- Card Thickness:0.062" (1.57mm)
- Number of Rows:2
- Pitch:0.100" (2.54mm)
- Read Out:Dual
- Features:Card Extender
- Mounting Type:Board Edge, Straddle Mount
- Termination:Solder Eyelet(s)
- Contact Material:Phosphor Bronze
- Contact Finish:Gold
- Contact Finish Thickness:30.0µin (0.76µm)
- Contact Type:Full Bellows
- Color:Blue
- Flange Feature:Side Mount Opening, Unthreaded, 0.125" (3.18mm) Dia
- Operating Temperature:-65°C ~ 125°C
