A6D10DS29A2
TE Connectivity AMP Connectors
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN EDGE DUAL FMALE 20POS 0.156
- CategoryCard Edge Connectors - Edgeboard Connectors
- Datasheet A6D10DS29A2 Datasheet
-
ECAD Model
- Share
In Stock: 190
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:-
- Package:Bulk
- Part Status:Active
- Card Type:Non Specified - Dual Edge
- Gender:Female
- Number of Positions/Bay/Row:-
- Number of Positions:20
- Card Thickness:-
- Number of Rows:2
- Pitch:0.156" (3.96mm)
- Read Out:Dual
- Features:-
- Mounting Type:Through Hole
- Termination:Solder
- Contact Material:Copper Alloy
- Contact Finish:Gold
- Contact Finish Thickness:30.0µin (0.76µm)
- Contact Type:-
- Color:Black
- Flange Feature:Top Mount Opening, Unthreaded, 0.125" (3.18mm) Dia
- Operating Temperature:-55°C ~ 125°C
