3-145090-4
TE Connectivity AMP Connectors
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN EDGE DUAL FMALE 130POS .050
- CategoryCard Edge Connectors - Edgeboard Connectors
- Datasheet 3-145090-4 Datasheet
-
ECAD Model
- Share
In Stock: 157
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:Standard Edge .050
- Package:Bulk
- Part Status:Active
- Card Type:Non Specified - Dual Edge
- Gender:Female
- Number of Positions/Bay/Row:-
- Number of Positions:130
- Card Thickness:0.054" ~ 0.070" (1.37mm ~ 1.78mm)
- Number of Rows:2
- Pitch:0.050" (1.27mm)
- Read Out:Dual
- Features:Board Lock
- Mounting Type:Through Hole
- Termination:Solder, Staggered
- Contact Material:Phosphor Bronze
- Contact Finish:Gold
- Contact Finish Thickness:30.0µin (0.76µm)
- Contact Type:-
- Color:-
- Flange Feature:-
- Operating Temperature:-55°C ~ 85°C
