CSR0805FTR100
Stackpole Electronics, Inc.
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionRES 0.1 OHM 1% 1/4W 0805
- CategoryChip Resistor - Surface Mount
- Datasheet CSR0805FTR100 Datasheet
-
ECAD Model
- Share
In Stock: 197
Can ship immediately
Pricing:
- 1$0.36
- 5,000$0.0567
- 10,000$0.05544
- 25,000$0.05355
- 50,000$0.0525
- 125,000$0.052
Quote It
Technical Details
- Series:CSR
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Resistance:100 mOhms
- Tolerance:±1%
- Power (Watts):0.25W, 1/4W
- Composition:Thick Film
- Features:Current Sense
- Temperature Coefficient:±200ppm/°C
- Operating Temperature:-55°C ~ 155°C
- Package / Case:0805 (2012 Metric)
- Supplier Device Package:0805
- Ratings:-
- Size / Dimension:0.079" L x 0.049" W (2.00mm x 1.25mm)
- Height - Seated (Max):0.026" (0.65mm)
- Number of Terminations:2
- Failure Rate:-
