ERJ-M1WSF20MU
Panasonic
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionRES 0.02 OHM 1% 1W 2512
- CategoryChip Resistor - Surface Mount
- Datasheet ERJ-M1WSF20MU Datasheet
-
ECAD Model
- Share
In Stock: 122
Can ship immediately
Pricing:
- 1$0.61
- 3,000$0.14928
- 6,000$0.1465
- 15,000$0.1407
- 30,000$0.13792
Quote It
Technical Details
- Series:ERJ-M1W
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Not For New Designs
- Resistance:20 mOhms
- Tolerance:±1%
- Power (Watts):1W
- Composition:Metal Element
- Features:Current Sense
- Temperature Coefficient:±100ppm/°C
- Operating Temperature:-55°C ~ 170°C
- Package / Case:2512 (6432 Metric)
- Supplier Device Package:2512
- Ratings:-
- Size / Dimension:0.252" L x 0.126" W (6.40mm x 3.20mm)
- Height - Seated (Max):0.043" (1.10mm)
- Number of Terminations:2
- Failure Rate:-
