CHP0805AFX-5600ELF
J.W. Miller / Bourns
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionRESHIGHPOWERA 0805 560R 1% 1/2W
- CategoryChip Resistor - Surface Mount
-
ECAD Model
- Share
In Stock: 5,051
Can ship immediately
Pricing:
- 1$0.7
Quote It
Technical Details
- Series:CHP-A
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Resistance:560 Ohms
- Tolerance:±1%
- Power (Watts):0.5W, 1/2W
- Composition:Thick Film
- Features:Anti-Sulfur, Automotive AEC-Q200, Moisture Resistant, Pulse Withstanding
- Temperature Coefficient:±100ppm/°C
- Operating Temperature:-55°C ~ 155°C
- Package / Case:0805 (2012 Metric)
- Supplier Device Package:0805
- Ratings:AEC-Q200
- Size / Dimension:0.079" L x 0.049" W (2.00mm x 1.25mm)
- Height - Seated (Max):0.024" (0.60mm)
- Number of Terminations:2
- Failure Rate:-
