CSS2H-2512R-L500F
J.W. Miller / Bourns
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionRES SMD 500 UOHM 1% 6W 2512
- CategoryChip Resistor - Surface Mount
- Datasheet CSS2H-2512R-L500F Datasheet
-
ECAD Model
- Share
In Stock: 103
Can ship immediately
Pricing:
- 1$1.03
- 3,000$0.34125
- 6,000$0.33469
- 15,000$0.32681
- 30,000$0.31763
Quote It
Technical Details
- Series:CSS2H-2512
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Resistance:500 µOhms
- Tolerance:±1%
- Power (Watts):6W
- Composition:Metal Element
- Features:Current Sense, Moisture Resistant
- Temperature Coefficient:±50ppm/°C
- Operating Temperature:-55°C ~ 170°C
- Package / Case:2512 (6432 Metric)
- Supplier Device Package:2512
- Ratings:-
- Size / Dimension:0.250" L x 0.120" W (6.35mm x 3.05mm)
- Height - Seated (Max):0.037" (0.94mm)
- Number of Terminations:2
- Failure Rate:-
