RMCF1206JT560R
Stackpole Electronics, Inc.
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionRES 560 OHM 5% 1/4W 1206
- CategoryChip Resistor - Surface Mount
- Datasheet RMCF1206JT560R Datasheet
-
ECAD Model
- Share
In Stock: 156
Can ship immediately
Pricing:
- 1$0.1
- 5,000$0.00339
- 10,000$0.00295
- 25,000$0.00259
- 50,000$0.00237
- 125,000$0.00233
Quote It
Technical Details
- Series:RMCF
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Resistance:560 Ohms
- Tolerance:±5%
- Power (Watts):0.25W, 1/4W
- Composition:Thick Film
- Features:Automotive AEC-Q200
- Temperature Coefficient:±200ppm/°C
- Operating Temperature:-55°C ~ 155°C
- Package / Case:1206 (3216 Metric)
- Supplier Device Package:1206
- Ratings:AEC-Q200
- Size / Dimension:0.126" L x 0.063" W (3.20mm x 1.60mm)
- Height - Seated (Max):0.028" (0.70mm)
- Number of Terminations:2
- Failure Rate:-
