PWR3014W20R0FE
J.W. Miller / Bourns
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionRES SMD 20 OHM 1% 1W 3014
- CategoryChip Resistor - Surface Mount
- Datasheet PWR3014W20R0FE Datasheet
-
ECAD Model
- Share
In Stock: 182
Can ship immediately
Pricing:
- 1$0.5453
- 1,500$0.5453
Quote It
Technical Details
- Series:PWR3014
- Package:Tape & Reel (TR)
- Part Status:Active
- Resistance:20 Ohms
- Tolerance:±1%
- Power (Watts):1W
- Composition:Wirewound
- Features:Current Sense, Pulse Withstanding
- Temperature Coefficient:±20ppm/°C
- Operating Temperature:-55°C ~ 155°C
- Package / Case:3014 J-Lead
- Supplier Device Package:3014
- Ratings:-
- Size / Dimension:0.295" L x 0.138" W (7.50mm x 3.50mm)
- Height - Seated (Max):0.203" (5.15mm)
- Number of Terminations:2
- Failure Rate:-
