PWR4525W6800J
J.W. Miller / Bourns
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionRES SMD 680 OHM 5% 2W 4525
- CategoryChip Resistor - Surface Mount
- Datasheet PWR4525W6800J Datasheet
-
ECAD Model
- Share
In Stock: 192
Can ship immediately
Pricing:
- 1$0.736
- 500$0.736
Quote It
Technical Details
- Series:PWR4525
- Package:Bulk
- Part Status:Active
- Resistance:680 Ohms
- Tolerance:±5%
- Power (Watts):2W
- Composition:Wirewound
- Features:Current Sense, Moisture Resistant, Pulse Withstanding
- Temperature Coefficient:±20ppm/°C
- Operating Temperature:-55°C ~ 275°C
- Package / Case:4525 J-Lead
- Supplier Device Package:-
- Ratings:-
- Size / Dimension:0.449" L x 0.252" W (11.40mm x 6.40mm)
- Height - Seated (Max):0.197" (5.00mm)
- Number of Terminations:2
- Failure Rate:-
