PWR263S-35-5600JE
J.W. Miller / Bourns
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionRES 560 OHM 5% 35W D2PAK
- CategoryChip Resistor - Surface Mount
- Datasheet PWR263S-35-5600JE Datasheet
-
ECAD Model
- Share
In Stock: 170
Can ship immediately
Pricing:
- 1$2.3275
- 1,000$2.31525
Quote It
Technical Details
- Series:PWR263S-35
- Package:Tube
- Part Status:Active
- Resistance:560 Ohms
- Tolerance:±5%
- Power (Watts):35W
- Composition:Thick Film
- Features:Automotive AEC-Q200, Current Sense, Pulse Withstanding
- Temperature Coefficient:±100ppm/°C
- Operating Temperature:-55°C ~ 155°C
- Package / Case:TO-263-3, D²Pak (2 Leads + Tab), TO-263AB
- Supplier Device Package:D2PAK
- Ratings:AEC-Q200
- Size / Dimension:0.398" L x 0.409" W (10.10mm x 10.40mm)
- Height - Seated (Max):0.177" (4.50mm)
- Number of Terminations:2
- Failure Rate:-
