HVCB2512BDC1M00
Stackpole Electronics, Inc.
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionRES 1M OHM 0.1% 2W 2512
- CategoryChip Resistor - Surface Mount
- Datasheet HVCB2512BDC1M00 Datasheet
-
ECAD Model
- Share
In Stock: 130
Can ship immediately
Pricing:
- 1$8.2225
- 500$7.84875
Quote It
Technical Details
- Series:HVC
- Package:Tape & Reel (TR)
- Part Status:Active
- Resistance:1 MOhms
- Tolerance:±0.1%
- Power (Watts):2W
- Composition:Thick Film
- Features:High Voltage, Moisture Resistant, Pulse Withstanding
- Temperature Coefficient:±50ppm/°C
- Operating Temperature:-55°C ~ 150°C
- Package / Case:2512 (6432 Metric)
- Supplier Device Package:2512
- Ratings:-
- Size / Dimension:0.250" L x 0.125" W (6.35mm x 3.18mm)
- Height - Seated (Max):0.030" (0.76mm)
- Number of Terminations:2
- Failure Rate:-
Related Products
RES SMD 1.2 OHM 5% 1/20W 0201
- 1: $0.00100
RES SMD 240K OHM 5% 1/20W 0201
- 1: $0.00100
RES SMD 2.2K OHM 5% 1/20W 0201
