HPC12JT22R0
Stackpole Electronics, Inc.
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionRES 22 OHM 5% 5W 5048 WIDE
- CategoryChip Resistor - Surface Mount
- Datasheet HPC12JT22R0 Datasheet
-
ECAD Model
- Share
In Stock: 187
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:HPC
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Obsolete
- Resistance:22 Ohms
- Tolerance:±5%
- Power (Watts):5W
- Composition:Thick Film
- Features:Non-Inductive, Pulse Withstanding
- Temperature Coefficient:±150ppm/°C
- Operating Temperature:-55°C ~ 155°C
- Package / Case:Wide 5048 (127122 Metric) 4850 J-Lead
- Supplier Device Package:SMD
- Ratings:-
- Size / Dimension:0.480" L x 0.500" W (12.19mm x 12.70mm)
- Height - Seated (Max):0.400" (10.16mm)
- Number of Terminations:2
- Failure Rate:-
