RCWL2512R560JNEA
Vishay / Dale
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionRES 0.56 OHM 5% 1W 2512
- CategoryChip Resistor - Surface Mount
- Datasheet RCWL2512R560JNEA Datasheet
-
ECAD Model
- Share
In Stock: 2,844
Can ship immediately
Pricing:
- 1$0.6
- 2,000$0.16011
- 6,000$0.15712
- 10,000$0.15091
- 50,000$0.14637
Quote It
Technical Details
- Series:RCWL
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Resistance:560 mOhms
- Tolerance:±5%
- Power (Watts):1W
- Composition:Thick Film
- Features:Automotive AEC-Q200, Current Sense, Moisture Resistant
- Temperature Coefficient:±200ppm/°C
- Operating Temperature:-55°C ~ 155°C
- Package / Case:2512 (6432 Metric)
- Supplier Device Package:2512
- Ratings:AEC-Q200
- Size / Dimension:0.248" L x 0.124" W (6.30mm x 3.15mm)
- Height - Seated (Max):0.028" (0.70mm)
- Number of Terminations:2
- Failure Rate:-
