RCS080522R0JNEA
Vishay / Dale
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionRES SMD 22 OHM 5% 0.4W 0805
- CategoryChip Resistor - Surface Mount
- Datasheet RCS080522R0JNEA Datasheet
-
ECAD Model
- Share
In Stock: 12,008
Can ship immediately
Pricing:
- 1$0.2
- 5,000$0.02172
- 10,000$0.02027
- 25,000$0.01925
- 50,000$0.01886
- 125,000$0.01876
Quote It
Technical Details
- Series:RCS e3
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Resistance:22 Ohms
- Tolerance:±5%
- Power (Watts):0.4W, 2/5W
- Composition:Thick Film
- Features:Automotive AEC-Q200, Pulse Withstanding
- Temperature Coefficient:±200ppm/°C
- Operating Temperature:-55°C ~ 155°C
- Package / Case:0805 (2012 Metric)
- Supplier Device Package:0805
- Ratings:AEC-Q200
- Size / Dimension:0.079" L x 0.049" W (2.00mm x 1.25mm)
- Height - Seated (Max):0.020" (0.50mm)
- Number of Terminations:2
- Failure Rate:-
