WSLP1206R0200FEA
Vishay / Dale
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionRES 0.02 OHM 1% 1W 1206
- CategoryChip Resistor - Surface Mount
- Datasheet WSLP1206R0200FEA Datasheet
-
ECAD Model
- Share
In Stock: 24,666
Can ship immediately
Pricing:
- 1$0.8
- 4,000$0.29068
- 8,000$0.28472
- 12,000$0.27632
- 28,000$0.26924
Quote It
Technical Details
- Series:WSLP
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Resistance:20 mOhms
- Tolerance:±1%
- Power (Watts):1W
- Composition:Metal Element
- Features:Anti-Sulfur, Automotive AEC-Q200, Current Sense, Moisture Resistant, Pulse Withstanding
- Temperature Coefficient:±75ppm/°C
- Operating Temperature:-65°C ~ 170°C
- Package / Case:1206 (3216 Metric)
- Supplier Device Package:1206
- Ratings:AEC-Q200
- Size / Dimension:0.126" L x 0.063" W (3.20mm x 1.60mm)
- Height - Seated (Max):0.035" (0.89mm)
- Number of Terminations:2
- Failure Rate:-
