CRCW0603560RJNEAHP
Vishay / Dale
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionRES SMD 560 OHM 5% 1/3W 0603
- CategoryChip Resistor - Surface Mount
- Datasheet CRCW0603560RJNEAHP Datasheet
-
ECAD Model
- Share
In Stock: 4,944
Can ship immediately
Pricing:
- 1$0.15
- 5,000$0.01685
- 10,000$0.01573
- 25,000$0.01494
- 50,000$0.01464
- 125,000$0.01455
Quote It
Technical Details
- Series:CRCW-HP
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Resistance:560 Ohms
- Tolerance:±5%
- Power (Watts):0.333W, 1/3W
- Composition:Thick Film
- Features:Automotive AEC-Q200, Pulse Withstanding
- Temperature Coefficient:±200ppm/°C
- Operating Temperature:-55°C ~ 155°C
- Package / Case:0603 (1608 Metric)
- Supplier Device Package:0603
- Ratings:AEC-Q200
- Size / Dimension:0.063" L x 0.033" W (1.60mm x 0.85mm)
- Height - Seated (Max):0.022" (0.55mm)
- Number of Terminations:2
- Failure Rate:-
