PS0306DRF7T0R01L
Yageo
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionRES 0.01 OHM 0.5% 1/2W 0603
- CategoryChip Resistor - Surface Mount
- Datasheet PS0306DRF7T0R01L Datasheet
-
ECAD Model
- Share
In Stock: 2,209
Can ship immediately
Pricing:
- 1$0.53
- 5,000$0.20235
- 10,000$0.19759
Quote It
Technical Details
- Series:PS
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Resistance:10 mOhms
- Tolerance:±0.5%
- Power (Watts):0.5W, 1/2W
- Composition:Metal Element
- Features:Current Sense
- Temperature Coefficient:±100ppm/°C
- Operating Temperature:-55°C ~ 125°C
- Package / Case:Wide 0603 (1608 Metric), 0306
- Supplier Device Package:0306
- Ratings:-
- Size / Dimension:0.063" L x 0.031" W (1.60mm x 0.80mm)
- Height - Seated (Max):0.028" (0.70mm)
- Number of Terminations:4
- Failure Rate:-
