PTN0402E1472BST1
Vishay
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionRES 14.7K OHM 0.1% 1/20W 0402
- CategoryChip Resistor - Surface Mount
- Datasheet PTN0402E1472BST1 Datasheet
-
ECAD Model
- Share
In Stock: 1,203
Can ship immediately
Pricing:
- 1$0.63
- 1,000$0.2175
Quote It
Technical Details
- Series:PTN
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Resistance:14.7 kOhms
- Tolerance:±0.1%
- Power (Watts):0.05W, 1/20W
- Composition:Thin Film
- Features:Anti-Sulfur, Moisture Resistant, Non-Inductive
- Temperature Coefficient:±25ppm/°C
- Operating Temperature:-55°C ~ 155°C
- Package / Case:0402 (1005 Metric)
- Supplier Device Package:0402
- Ratings:-
- Size / Dimension:0.042" L x 0.022" W (1.07mm x 0.56mm)
- Height - Seated (Max):0.033" (0.84mm)
- Number of Terminations:2
- Failure Rate:-
