820B005-103R001
NorComp
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN PLUG MALE 5P GOLD SLDR CUP
- CategoryCircular Connectors
- Datasheet 820B005-103R001 Datasheet
-
ECAD Model
- Share
In Stock: 156
Can ship immediately
Pricing:
- 1$22.76
- 10$20.541
- 36$19.68
- 72$18.45
- 108$17.835
- 252$16.85099
- 504$16.35901
Quote It
Technical Details
- Series:QUIK-LOQ™ 820B
- Package:Tray
- Part Status:Active
- Connector Type:Plug, Male Pins
- Number of Positions:5
- Shell Size - Insert:-
- Shell Size, MIL:-
- Mounting Type:Panel Mount
- Mounting Feature:Bulkhead - Rear Side Nut
- Termination:Solder Cup
- Fastening Type:Push-Pull
- Orientation:Keyed
- Shell Material:Brass
- Shell Finish:Nickel
- Contact Finish - Mating:Gold
- Color:Silver
- Ingress Protection:IP50 - Dust Protected
- Material Flammability Rating:-
- Features:-
- Shielding:Shielded
- Current Rating (Amps):6.5A
- Voltage Rating:280V
- Cable Opening:0.323" (8.20mm)
- Operating Temperature:-40°C ~ 200°C
