MB3ZSN8HS3
Tuchel / Amphenol
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN RCPT HSG MALE 5POS INLINE
- CategoryCircular Connectors - Housings
- Datasheet MB3ZSN8HS3 Datasheet
-
ECAD Model
- Share
In Stock: 140
Can ship immediately
Pricing:
- 1$33.89
- 10$32.08169
- 25$31.17563
- 50$29.36309
- 100$27.91307
Quote It
Technical Details
- Series:MotionGrade™ M23 Hybrid Series, Threaded
- Package:Bulk
- Part Status:Active
- Connector Type:Receptacle Housing
- Type:For Male Pins
- Number of Positions:5 (1 + 2 Power + 1 Quadrax + PE)
- Shell Size - Insert:M23-5
- Shell Size, MIL:-
- Contact Type:Crimp
- Contact Size:1.0mm (1), 2.0mm Power (3), 0.7mm Quadrax (1)
- Mounting Type:Free Hanging (In-Line)
- Mounting Feature:-
- Fastening Type:Threaded
- Orientation:Keyed
- Shell Material:Zinc Die Cast
- Shell Finish:Nickel
- Housing Color:Silver
- Ingress Protection:IP67 - Dust Tight, Waterproof
- Material Flammability Rating:-
- Features:Backshell
- Shielding:Shielded
