MS27505E13B35B
PEI-Genesis
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN RCPT HSG FMALE 22POS PNL MT
- CategoryCircular Connectors - Housings
- Datasheet MS27505E13B35B Datasheet
-
ECAD Model
- Share
In Stock: 134
Can ship immediately
Pricing:
- 1$35.32
- 5$30.96604
- 10$26.32866
- 25$24.24347
Quote It
Technical Details
- Series:Military, MIL-DTL-38999 Series I, LJT
- Package:Box
- Part Status:Active
- Connector Type:Receptacle Housing
- Type:For Female Sockets
- Number of Positions:22
- Shell Size - Insert:13-35
- Shell Size, MIL:-
- Contact Type:Crimp
- Contact Size:22D
- Mounting Type:Panel Mount
- Mounting Feature:Flange
- Fastening Type:Bayonet Lock
- Orientation:N (Normal)
- Shell Material:Aluminum Alloy
- Shell Finish:Cadmium over Nickel
- Housing Color:Olive Drab
- Ingress Protection:Environment Resistant
- Material Flammability Rating:-
- Features:-
- Shielding:Unshielded
