D38999/20WJ4AB
PEI-Genesis
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionAE3 56C 48#20, 8#16 PIN RECP
- CategoryCircular Connectors - Housings
-
ECAD Model
- Share
In Stock: 189
Can ship immediately
Pricing:
- 1$53.1
- 10$49.97754
- 25$48.41584
- 50$45.29242
- 100$42.7934
Quote It
Technical Details
- Series:Military, MIL-DTL-38999 Series III, Tri-Start™ TV
- Package:Box
- Part Status:Active
- Connector Type:Receptacle Housing
- Type:For Male Pins
- Number of Positions:56
- Shell Size - Insert:25-4
- Shell Size, MIL:J
- Contact Type:Crimp
- Contact Size:16 (8), 20 (48)
- Mounting Type:Panel Mount
- Mounting Feature:Flange
- Fastening Type:Threaded
- Orientation:B
- Shell Material:Aluminum
- Shell Finish:Cadmium
- Housing Color:Olive Drab
- Ingress Protection:Environment Resistant
- Material Flammability Rating:-
- Features:-
- Shielding:Shielded
