D38999/26WJ4PA-LC
PEI-Genesis
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionAE3 56C 48#20, 8#16 PIN PLUG
- CategoryCircular Connectors - Housings
- Datasheet D38999/26WJ4PA-LC Datasheet
-
ECAD Model
- Share
In Stock: 175
Can ship immediately
Pricing:
- 1$58.86
- 5$53.61538
- 10$47.78692
- 25$45.16477
- 50$42.25077
- 100$39.62831
Quote It
Technical Details
- Series:Military, MIL-DTL-38999 Series III, Tri-Start™ TV
- Package:Box
- Part Status:Active
- Connector Type:Plug Housing
- Type:For Male Pins
- Number of Positions:56
- Shell Size - Insert:25-4
- Shell Size, MIL:J
- Contact Type:Crimp
- Contact Size:16 (8), 20 (48)
- Mounting Type:Free Hanging (In-Line)
- Mounting Feature:-
- Fastening Type:Threaded
- Orientation:A
- Shell Material:Aluminum
- Shell Finish:Cadmium
- Housing Color:Olive Drab
- Ingress Protection:Environment Resistant
- Material Flammability Rating:-
- Features:Coupling Nut, Self Locking
- Shielding:Shielded
