- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN PLUG HSNG MALE 47POS INLINE
- CategoryCircular Connectors - Housings
- Datasheet HDP26-24-47PE Datasheet
-
ECAD Model
- Share
In Stock: 356
Can ship immediately
Pricing:
- 1$17.3
- 10$15.61344
- 25$14.95915
- 50$14.02421
- 100$13.55673
- 250$12.80878
- 500$12.4348
Quote It
Technical Details
- Series:HDP20
- Package:Bulk
- Part Status:Active
- Connector Type:Plug Housing
- Type:For Male Pins
- Number of Positions:47
- Shell Size - Insert:24-47
- Shell Size, MIL:-
- Contact Type:Crimp
- Contact Size:16 (5), 20 (42)
- Mounting Type:Free Hanging (In-Line)
- Mounting Feature:-
- Fastening Type:Bayonet Lock
- Orientation:Keyed
- Shell Material:Polyamide (PA66), Nylon 6/6, Glass Filled
- Shell Finish:-
- Housing Color:Black
- Ingress Protection:IP68 - Dust Tight, Waterproof
- Material Flammability Rating:UL94 V-1
- Features:Coupling Nut
- Shielding:Unshielded
