- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN PLUG HSG MALE 29POS INLINE
- CategoryCircular Connectors - Housings
- Datasheet HD36-24-29PE Datasheet
-
ECAD Model
- Share
In Stock: 253
Can ship immediately
Pricing:
- 1$25.73
- 10$23.23065
- 25$22.25657
- 50$20.86553
- 100$20.17002
- 250$19.05721
- 500$18.50077
Quote It
Technical Details
- Series:HD30
- Package:Bulk
- Part Status:Active
- Connector Type:Plug Housing
- Type:For Male Pins
- Number of Positions:29
- Shell Size - Insert:24-29
- Shell Size, MIL:-
- Contact Type:Crimp
- Contact Size:12 (4), 16 (19), 20 (6)
- Mounting Type:Free Hanging (In-Line)
- Mounting Feature:-
- Fastening Type:Bayonet Lock
- Orientation:Keyed
- Shell Material:Aluminum
- Shell Finish:-
- Housing Color:Silver
- Ingress Protection:IP67 - Dust Tight, Waterproof
- Material Flammability Rating:-
- Features:Coupling Nut
- Shielding:Unshielded
