796332-1
TE Connectivity AMP Connectors
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN PLG HSG MALE 16POS INLINE
- CategoryCircular Connectors - Housings
- Datasheet 796332-1 Datasheet
-
ECAD Model
- Share
In Stock: 241
Can ship immediately
Pricing:
- 1$23.6
- 10$21.29935
- 25$20.40632
- 50$19.13066
- 100$18.49307
- 250$17.47275
- 500$16.96258
Quote It
Technical Details
- Series:CPC Series 6
- Package:Bulk
- Part Status:Active
- Connector Type:Plug Housing
- Type:For Male Pins
- Number of Positions:16 (12 + 4 Power)
- Shell Size - Insert:23-16
- Shell Size, MIL:-
- Contact Type:Crimp
- Contact Size:16 (12), 8 Power (4)
- Mounting Type:Free Hanging (In-Line)
- Mounting Feature:-
- Fastening Type:Threaded
- Orientation:Keyed
- Shell Material:Polyamide (PA), Nylon
- Shell Finish:-
- Housing Color:Black
- Ingress Protection:IP65/IP67 - Dust Tight, Water Resistant, Waterproof
- Material Flammability Rating:UL94 V-0
- Features:Coupling Nut
- Shielding:Unshielded
