- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN PLUG HSG FMALE 14POS INLINE
- CategoryCircular Connectors - Housings
- Datasheet HDP26-24-14SN Datasheet
-
ECAD Model
- Share
In Stock: 250
Can ship immediately
Pricing:
- 1$17.12
- 10$15.90048
- 25$14.2691
- 50$13.86151
- 100$12.23075
- 250$11.41536
- 500$11.17075
Quote It
Technical Details
- Series:HDP20
- Package:Bulk
- Part Status:Active
- Connector Type:Plug Housing
- Type:For Female Sockets
- Number of Positions:14
- Shell Size - Insert:24-14
- Shell Size, MIL:-
- Contact Type:Crimp
- Contact Size:4 (1), 12 (1), 16 (12)
- Mounting Type:Free Hanging (In-Line)
- Mounting Feature:-
- Fastening Type:Bayonet Lock
- Orientation:Keyed
- Shell Material:Polyamide (PA66), Nylon 6/6, Glass Filled
- Shell Finish:-
- Housing Color:Black
- Ingress Protection:IP68 - Dust Tight, Waterproof
- Material Flammability Rating:UL94 V-1
- Features:Coupling Nut
- Shielding:Unshielded
